LSYA-BD02 Light Dual Use Full Electric Nursing Bed
Product parameter training
I. Product parameters
This product is a manual electric integrated full bend leg nursing bed
1. DH02 Specifications:
Dimensions: Length 2080mm, width 960mm, bed body standard height 560mm(including mattress).
Stool hole size: 310X230mm
2. Functions:
1) The number of motors is 4, and the left and right turns share the same motor to promote the work. The motor is always thrust oriented, the force is uniform and the power is stable. One motor is responsible for one function to prolong the service life of the motor. Electric five functions (electric left and right turn over, electric rise, electric leg position lifting, electric sitting switch), and a timing turn over function and the back of the side slide function.
2) Manual operation function
When the power failure, the user also needs normal care, can be manually operated to complete each function. Avoid the power outage caused by the difficulty of nursing care.
3) Set the timing turning time
Can be set in 35 or 45 minutes according to user needs, better to meet user needs.
4) Adjustment range: back can be lifted Angle: 0-75°
Leg position can be raised or lowered from +25° to -75°
Side turning up and down Angle: 0-45°
5) aluminum alloy guardrail:
's side fence is 1150 mm, armrest, D type aluminum alloy surface hardening treatment, 5 pieces of stainless steel barrier pillars, and connectors used a steel stamping parts, the thickness of 2.5 mm, switch is designed to ensure the safety of long-term use, equipped with elastic firmware prevention, wear-resisting, not deformation, retractable flat, contracting slightly above the bed surface, can prevent the displacement of the mattress.
6) Headboard and tail board:
ABS engineering plastic, embellished with blue mold blow molding, fade resistance, aging resistance, corrosion resistance and easy to clean. A transparent medical record card is installed at the end of the bed. The head of the bed and the end of the bed can be disassembled freely without the help of any tools.
7) Move the mute caster:
Convenient free movement; At the same time with a brake device to fix the bed, the diameter of the caster 12cm, built-in double
Bearing, fork adopts cold plate 2.5mm (thickness) one stamping molding, tread is soft tread.
8) Mattress:
Double mattress cover: the outer layer is made of pure cotton cloth, and the inner layer is waterproof cloth cover to prevent liquid from contaminating the inner tank. The inner material is made of 4cm hard brown wire with good air permeability, 2cm high density sponge with good resilience, and the stool hole is made of waterproof fabric, which is treated with insect control. The appearance is beautiful and easy to remove and wash.
9) The load-bearing material of the urinal door is a solid steel rod with a diameter of 20mm, which can effectively support the hip strength and ensure that there will be no subsidence and no return after long-term use. The position of the toilet mouth mattress and the toilet mouth is designed with adhesive, so there is no need to move the nursing staff to take the mattress away. And equipped with adjustable height device, such as in the process of using the mouth subsidence, can be adjusted to restore the original position. The bearing plate of the container under the mouth is formed by the steel plate with a thickness of 1.2mm, which is safe and reliable.
10) Back lifting pulley design:
It is equipped with 4 wide pulleys to avoid noise and damage caused by friction between bed bodies for a long time. Reduce friction, reduce the burden of nursing staff.
11) Rounded frame design:
The rounded frame design is not simple and beautiful, but also increases the integrity of the whole frame, and avoids scratches on the bedding and mattress when using.
12) The infusion stand is of lifting type, and the height can be adjusted according to user's requirements. The supervisor IS made of high quality 304 stainless steel tube, with three hooks, which can carry out multiple bottles of infusion at the same time, and can be folded and stored at the head of the bed when not in use.
13) Design of leg touchdown pulley
When THE leg descends to CONTACT WITH the GROUND, THE small black wheel at the bottom of the leg is equipped to roll with the ground to avoid scratching the floor.
14) One-button reset function
Click the reset function button, the nursing bed can return to the lying state, do not need to restore each functional state in turn, simplify the operation process.
15) Handle luminous function
Click any function key, the light of all function keys on the handle will light up, which is convenient for users to use at night.
16) The bed body can bear weight of 300㎏.
3. Material:
1) Bed bed adopts 40×60 square tube with a thickness of 1.2mm. The bed surface is made of 15×30 square tubes with a thickness of 1.2mm. Bed connectors are made of thick wall 2.75mm pipe or 3mm cold plate.
2) Welding process;
The bed frame and bed surface are welded by robot, welding is firm, welding is smooth and durable.
3) Bed spraying process:
Bed surface after steel shot sandblasting rust, electrostatic spraying, bed coated with antistatic powder, acid and alkali corrosion, fade resistance.
4. Product configuration
Control handle, control box, power cord, silent wheel, aluminum alloy guardrail, dining table, 6cm mattress, colored cotton bedspread, shampoo basin, bedpan, infusion stand, ABS head and tail, manual, warranty card
5. Product packaging
1) Because the steel used by Yonghui nursing bed should be thick, so the weight of the product should reach 100kg. In order to ensure that the product can reach the hands of customers in good condition, the packaging of Yonghui nursing bed is made of special thickened corrugated carton, and the built-in double pad.
2) The quantity of product packaging is divided into 2 pieces.
Bed packing box size; 1500 long 970 wide 430 high
Headcase dimensions: 970 x 140 x 550
The total volume is 0.72 cubic
