LSYA-D201 Electric Bed with Two Functions
1, Specification size: length :2050mm, width :960mm, height :500mm.
Back tilt: 0°-75° Leg tilt Angle: 0 ~ 35° can be adjusted arbitrarily,
2. Product material:
(1) The bed frame is made of high quality carbon steel rectangular steel pipe with length 40mm× width 60mm× thickness 1.2mm:
(2) the bed panel is formed by high-quality cold rolled carbon steel sheet 1.2mm at a time to improve the strength of the bed plate, balanced force, strong pressure resistance, and with air holes, and anti-slip function; The welded steel pipe below is reinforced, solid and durable. :
(3) The foot of the bed is made of high quality carbon steel rectangular steel pipe with length 40mm× width 40mm× thickness 1.2mm:
(4) The net weight of the bed is 69Kg.
2. Two groups of motor; The motor is always thrust oriented, uniform force, stable power, back function, leg bending function, overall lifting function, one motor is responsible for one function, prolong the service life of the motor.
4. The headboard and tail board are made of advanced ABS material by injection molding. The color of the head board is light blue, the locking parts are made of steel parts, and the symmetrical quick socket can be quickly disassembled.
5. The bed body can carry 240Kg static and 200Kg dynamic; Double support structure is adopted AT the bottom of the bed surface to strengthen the bearing force of the backboard. The rocker can bear little pressure and save effort when shaking.
6. The head of the bed and the end of the bed are equipped with infusion jacks, and the sides of the bed frame are equipped with drainage hooks.
7, the whole bed after surface treatment for many times electrostatic spray, so that it has a more perfect appearance and strong chemical corrosion resistance, spray material environmental protection non-toxic.
8, aluminum alloy guardrail: 's side fence is 1200 mm, armrest, D type aluminum alloy surface hardening treatment, 5 pieces of stainless steel barrier pillars, and connectors used a steel stamping parts, the thickness of 2.5 mm, switch is designed to ensure the safety of long-term use, equipped with elastic firmware prevention, wear-resisting, not deformation, retractable flat, contracting slightly above the bed surface, can prevent the displacement of the mattress.
9, mobile mute casters: easy to move freely; At the same time, it has a brake device to fix the bed, the diameter of the moving caster is 12cm, the built-in double bearings, the fork is formed by cold plate 2.5mm (thickness), and the tread is soft tread.
