LSYA-S202 Double rocking square tube bed with wheels
First, the bed parameters:
1. Specifications and dimensions: length: 2050mm, width: 960mm, height: 500mm.
Back tilt: 0°-75° Leg tilt angle: 0～35° can be adjusted arbitrarily,
2. Product material:
(1) The bed frame is made of high-quality carbon steel rectangular steel pipe with length 40mm × width 80mm × thickness 1.2mm;
(2) The bed panel is welded and formed by high-quality steel pipes with a length of 40mm × width of 20mm × thickness of 1.2mm, which is strong and practical;
(3) The feet of the bed are made of high-quality carbon steel rectangular steel pipes with a length of 40mm × width of 40mm × thickness of 1.2mm;
3. The screw of the hand shaker is made of 45# steel, the wall thickness of the screw is 3.0mm, the appearance of the lifting screw is smooth and durable, the rocker adopts the universal joint structure, and the two-way limit protection device is used, which is safe and reliable, easy to use and no noise ; And there are protective devices to prevent dust accumulation; the crank handle can be folded and folded.
4. The headboard and footboard of the bed are made of high-grade ABS material by blow molding at one time. The color of the headboard is light blue. The locking parts are all made of steel. The symmetrical quick socket can be quickly disassembled. The head plate is designed for collision-proof corners.
5. The total length of the side guardrail is 1200mm, D-type aluminum alloy handrail, surface hardening treatment, five aluminum alloy guardrail pillars, the upper and lower connecting parts are made of one-time stamping and forming steel parts, the thickness is 3.0mm, the switch is carefully designed to ensure the safety of long-term use, equipped with Anti-loosening fasteners, wear-resistant, non-deformable, can shrink and lay flat, slightly higher than the bed surface when shrinking, which can prevent the mattress from shifting.
6. The bed body can carry 240Kg statically and 200Kg dynamically; the bottom of the bed all adopts double support structure, which strengthens the bearing capacity of the backboard, the rocker bears less pressure, and the operation is labor-saving when shaking.
7. 5-inch high-grade casters are used, with built-in fully enclosed self-lubricating bearings, no need for refueling and nursing, preventing foreign objects from being involved, and independent braking; the wheel surface is made of TPR polymer wear-resistant material, which is wear-resistant and noise-free.
8. The dining table board is made of pp material, and the two ends are molded into a concave shelf with pp (anti-displacement), which is easy to clean and wear-resistant. The dining table board can be placed at the end of the bed, which is convenient for patients to use, safe and reliable.
9. The whole bed is electrostatically sprayed after multiple surface treatments, so that it has a more perfect appearance and strong chemical corrosion resistance, and the sprayed material is environmentally friendly and non-toxic. First, the bed parameters:
1. Specifications and dimensions: length: 2050mm, width: 960mm, height: 500mm.
Back tilt: 0°-75° Leg tilt angle: 0～35° can be adjusted arbitrarily,
2. Product material:
(1) The bed frame is made of high-quality carbon steel rectangular steel pipe with length 40mm × width 80mm × thickness 1.2mm;
(2) The bed panel is welded and formed by high-quality steel pipes with a length of 40mm × width of 20mm × thickness of 1.2mm, which is strong and practical;
(3) The feet of the bed are made of high-quality carbon steel rectangular steel pipes with a length of 40mm × width of 40mm × thickness of 1.2mm;
3. The screw of the hand shaker is made of 45# steel, the wall thickness of the screw is 3.0mm, the appearance of the lifting screw is smooth and durable, the rocker adopts the universal joint structure, and the two-way limit protection device is used, which is safe and reliable, easy to use and no noise ; And there are protective devices to prevent dust accumulation; the crank handle can be folded and folded.
4. The headboard and footboard of the bed are made of high-grade ABS material by blow molding at one time. The color of the headboard is light blue. The locking parts are all made of steel. The symmetrical quick socket can be quickly disassembled. The head plate is designed for collision-proof corners.
5. The total length of the side guardrail is 1200mm, D-type aluminum alloy handrail, surface hardening treatment, five aluminum alloy guardrail pillars, the upper and lower connecting parts are made of one-time stamping and forming steel parts, the thickness is 3.0mm, the switch is carefully designed to ensure the safety of long-term use, equipped with Anti-loosening fasteners, wear-resistant, non-deformable, can shrink and lay flat, slightly higher than the bed surface when shrinking, which can prevent the mattress from shifting.
6. The bed body can carry 240Kg statically and 200Kg dynamically; the bottom of the bed all adopts double support structure, which strengthens the bearing capacity of the backboard, the rocker bears less pressure, and the operation is labor-saving when shaking.
7. 5-inch high-grade casters are used, with built-in fully enclosed self-lubricating bearings, no need for refueling and nursing, preventing foreign objects from being involved, and independent braking; the wheel surface is made of TPR polymer wear-resistant material, which is wear-resistant and noise-free.
8. The dining table board is made of pp material, and the two ends are molded into a concave shelf with pp (anti-displacement), which is easy to clean and wear-resistant. The dining table board can be placed at the end of the bed, which is convenient for patients to use, safe and reliable.
9. The whole bed is electrostatically sprayed after multiple surface treatments, so that it has a more perfect appearance and strong chemical corrosion resistance, and the sprayed material is environmentally friendly and non-toxic.
