LSD-011
Lisa
1. Parameters:
Illumination (adjustable) 40,000-180,000Lux
Number of bulbs 61 + 39
Bulb type LED
Average bulb life ≥80，000h
Color temperature (adjustable) 3700K ～5000K
Display index (adjustable) 85～98
Focus depth 50-180cm
Spot diameter 160-280mm
Brightness adjustment 1%-100%
Power consumption (W) 65
The surgeon’s head heats up ﹤1℃
Power supply voltage AC100-240V 50/60HZ
2. The lamp holder is fixed on the balance arm suspension system by multiple lamp beads, and the positioning is stable. It can be moved vertically or cyclically, which can meet the needs of different heights and angles in the operation.
3. The elbow is an important structural part that connects the lamp holder and the balancer. The elbow can rotate the lamp holder through its own rotation.
4. The balancer can make the lamp holder achieve a stable balance effect at different angles, which can meet the actual use.
5. The rotating arm rotates by itself to change the position of the components in other positions, so as to meet the needs of the operator. The base is a structural part for fixing the shadowless lamp on the ceiling.
6. The entire shadowless lamp is composed of a mother lamp and a sub lamp. Both the mother lamp and the sub lamp include 8 groups of modules: each module of the mother lamp includes 10 lamp beads, seven of which are warm white, represented by yellow, three are cool white, represented by gray, and seven warm whites are connected in series. Group, three cool whites are connected in series to form a group, which is called high-brightness light-emitting diode string HBLEDs (High BrightnessLighting EmittingDiode); each module of the sub-lamp includes 6 lamp beads, four of which are warm white, represented by yellow, and two are Cool white, four warm whites are connected in series to form a group, and two cool whites are connected in series to form a group.
7. The handle of the shadowless lamp is used for focusing, and the diameter of the spot can be adjusted by rotating the handle. With marble structure, it is easy to disassemble.
8. Illumination adjustment shadowless lamp control panel. After the shadowless lamp is energized, the power indicator POWER (orange) on the control panel will be on; press the power switch button of the lamp head, the shadowless lamp will light up, according to the degree of brightening button, the illuminance of the shadowless lamp will gradually increase, and the brightness of the shadowless lamp will gradually decrease. ; A total of eight adjustments. The POWER indicator is always on when the power is on. The internal driver board is the core of the entire shadowless lamp controller, which is mainly composed of 16 MCU STC15F104E and 32-channel OCP2185 constant current voltage regulator circuit, and also contains TTL communication circuit. Power supply voltage: 5.5V-3.8V, can run with low power consumption, suitable for many occasions requiring high integration and low cost, and can meet various performance requirements. All 175℃ high temperature baking for eight hours, high-quality manufacturing guarantee.
